Hüper Optik™  Nano-ceramic series are made up of non-reactive, stable Titanium Nitride (TiN) compounds, which does not fade or corrode. The benefits of Huper Optik® Nano-ceramic series films are:

  • Superior Heat rejection performance
  • Superb Durability
  • Low visible light reflectance
Technical Specifications
Nano Ceramics Series VLT % VLR % (EXT) VLR % (INT) UVR % TSER % U-Value SC SHGC
Hüper Ceramics 50 53 12 10 > 99 45 1.06 0.63 0.55
Hüper Ceramics 60 61 11 9 > 99 39 1.06 0.71 0.61
Hüper Ceramics 70 73 8 9 > 99 44 1.04 0.64 0.56

Data captured using NFRC guidelines and calculated for single pane, 1/8" (3mm) clear glass. Reported values are taken from representative product samples and are subject to normal manufacturing variances. Actual performance will vary based on a number factors, including glass type and properties.
